PDCA 700 Automatic Double Clipper

The fully automatic double clipper of the PDC-A line is suitable for midsize to large production runs. This machine is capable of efficiently producing all types of products, including single portions or chains, long sausages, half rings, and rings. Once done, it is designed to close fibrous casings up to 105 mm calibre and plastic casings of even larger diameters. The food clipping machine also features an additional safety feature with the two-handed triggering of the first clip, ensuring maximum safety.

Technical data

Width

1260 — 1460 Millimetre

Height

1795 — 2005 Millimetre

Weight

142 Kilogram

Depth

780 Millimetre

Three-phase current connection

85 – 264 VAC, 50/60 Hz

Fuse connection

2.5 Ampere

Compressed air

   4 — 6 bar
